ILG steel pipe is fused zinc galvanized steel pipe that is produced in fused zinc galvanized facility that Jeongan Steel has introduced "for the first time in Korea". This system has improved the problem with corrosion of welded parts that existing PRE GALVANIZED(HGI, CGI) steel pipe has by reinforcing corrosion resistance to the level of fused zinc galvanized steel pipe and performing additional treatment process and complementing the damage of surface in producing pipe and this system has improved corrosion resistance remarkably .
This product is "environmentally friendly product" that applies inner coating selection method according to the use of pipe and this product is produced by applying precise control of amount to be galvanized and introduction of consecutive IN-LINE plating method and we have improved competitiveness by producing steel pipe in unified line .

- It is made from triple coating steel pipe of zinc, chrome, resin and has excellent corrosion resistance. (Corrosion resistance-salt water spray test white rust generation basis 200Hr)
- Corrosion resistance of welded part is as excellent as main body by consecutive zinc gilding and coating.
- It contains outstanding yield and tensile strength compared to general structural steel pipes.
- Paining steel pipe enables customers to reduce expenses by painting and cutting delivery system.
- We provide customers with competitiveness by reducing cost and preventing rust from generating through inner corrosion resistance resin coating.
- UV coating pipe can maintain the quality of surface by preventing surface being damaged in processing process and UV coating pipe is primarily for high corrosion resistance such as in bad weather district.
- Rigid conduit can minimize the damage of power line covering as rigid conduit has excellent corrosion resistance and the feature of slip by inner resin coating.

O.D(mm)	1.2	1.4	1.5	1.8	2	2.1	2.3	2.9	3.2
Thickness (mm)	1.2	1.4	1.5	1.8	2	2.1	2.3	2.9	3.2
21.7	0.607	0.701	0.747	0.883	0.972	1.02	1.10	1.34	1.46
22.2	0.621	0.718	0.766	0.906	0.996	1.04	1.13	1.38	1.50
25.4	0.716	0.829	0.884	1.05	1.15	1.21	1.31	1.61	1.75
26.7	0.755	0.873	0.932	1.11	1.22	1.27	1.38	1.70	1.85
31.8	0.906	1.05	1.12	1.33	1.47	1.54	1.67	2.07	2.26
34.0	0.971	1.13	1.20	1.43	1.58	1.65	1.80	2.22	2.43
33.4	0.953	1.10	1.18	1.40	1.55	1.62	1.76	2.18	2.38
42.7	1.23	1.43	1.52	1.82	2.01	2.10	2.29	2.85	3.12
48.1	1.39	1.61	1.72	2.06	2.27	2.38	2.60	3.23	3.54
48.6	1.4	1.63	1.74	2.08	2.30	2.41	2.63	3.27	3.58
60.5	1.75	2.04	2.18	2.61	2.89	3.02	3.30	4.12	4.52
75.5	2.2	2.56	2.74	3.27	3.63	3.80	4.15	5.19	5.71
50/50	1.81	2.10	2.24	2.66	2.93	3.07	3.34	4.12	4.50

* The part that is designated as spot color refers to the range that manufacturing is possible.
* If you have inquiry about measurement and thickness that is not listed above, please contact sales department.

O.D(mm)	1.2	1.5	1.9	2	2.1	2.3	3.2
Thickness (mm)	1.2	1.5	1.9	2	2.1	2.3	3.2
22.2	0.621	0.766	0.906	0.996	1.04	1.13	1.50
25.4	0.716	0.884	1.05	1.15	1.21	1.31	1.75
31.8	0.906	1.12	1.33	1.47	1.54	1.67	2.26
33.4	0.953	1.18	1.40	1.55	1.62	1.76	2.38
42.7	1.23	1.52	1.82	2.01	2.10	2.29	3.12
48.1	1.39	1.72	2.06	2.27	2.38	2.60	3.54
48.6	1.4	1.74	2.08	2.30	2.41	2.63	3.58
60.5	1.75	2.18	2.61	2.89	3.02	3.30	4.52

Thick steel conduit

Nominal	OD(mm)	OD allowance(mm)	Thickness(mm)	Weight(kg/m)	Length of effective screw section(mm)
Nominal	OD(mm)	OD allowance(mm)	Thickness(mm)	Weight(kg/m)	Max	Min
G16	21	±0.3	2.3	1.06	19	16
G22	26.5	±0.3	2.3	1.37	22	19
G28	33.3	±0.3	2.5	1.9	25	22
G36	41.9	±0.3	2.5	2.43	28	25
G42	47.8	±0.3	2.5	2.79	28	25
G54	59.2	±0.3	2.8	3.92	32	28
G70	75.2	±0.3	2.8	5	36	32

Post processing Division		COATING STRUCTURE	Features	Use
Outer side	Non-processing		Product that needs surface treatment like coating	Circular pipe for fence structure use, steel pipe for machinery structure use
	CHROMATED		Product that needs general corrosion resistance	Steel pipe for construction structure (single scaffolding, etc) steel pipe for general structure use steel pipe for farming use alternative to steel pipe for fused zinc galvanized
	Cr+UV coating		Product that needs the minimum of surface damage in subsequent processing like bending	Steel pipe of high corrosion resistance steel pipe for processing use
	PRE-PAINED		Product that uses by applying paint on zinc coating pipe coating adhesion is excellent by IN-LINE paintings	Fence structural barricade fire fighting use, fence structure use for conduit use, safety sign for, exercise equipment use.
Inner side	Non-processing		Product that needs interference free inside	Steel pipe for refrigerants
	Resin coating		Product that needs general corrosion resistance	Steel pipe for construction use (single pipe scaffolding, etc) steel pipe for general structure use steel pipe for farming use alternative to fused zinc galvanized general structure use
	ZINC-RICH		Product that needs high corrosion resistance in humid environment
